PRCML30-15DN Autonics Proximity Sensor
Autonics PRCML30-15DN Inductive Proximity Sensor – M30, 15 mm, NPN, DC 3-Wire (Connector Type)
Autonics PRCML30-15DN is an M30 connector-type inductive proximity sensor with 15 mm sensing distance and NPN DC 3-wire output.
Ideal for long-range metal detection in heavy-duty PLC-based industrial automation.
Customize
Share :
The Autonics PRCML30-15DN is a connector-type inductive proximity sensor designed for long-range detection of metal objects in industrial automation systems. With a rugged M30 threaded housing, 15 mm sensing distance (non-flush), and NPN DC 3-wire output, it is ideally suited for conveyors, bulk handling systems, steel plants, and heavy machinery where extended sensing distance and quick sensor replacement without rewiring are critical.
Key Features
Detects metal objects only (inductive sensing principle)
M30 connector-type design for easy maintenance
15 mm sensing distance (non-flush / unshielded)
NPN, DC 3-wire output
Long-range sensing for heavy-duty applications
Red LED operation indicator
Reverse polarity & short-circuit protection
IP67 protection for harsh industrial environments
Technical Specifications
| Parameter | Value |
|---|---|
| Model | PRCML30-15DN |
| Sensor Type | Inductive Proximity Sensor |
| Housing Size | M30 |
| Installation | Non-Flush (Unshielded) |
| Sensing Distance | 15 mm |
| Setting Distance | 0 – 10.5 mm |
| Standard Target | Iron 30 × 30 × 1 mm |
| Output Type | NPN |
| Wiring | DC 3-Wire |
| Supply Voltage | 12–24 V DC (10–30 V DC operating) |
| Current Consumption | ≤ 10 mA |
| Control Output | Max. 200 mA |
| Response Frequency | Approx. 100 Hz |
| Connection Type | Connector Type (M12 cable) |
| Indicator | Red LED |
| Protection Rating | IP67 |
| Ambient Temperature | −25 °C to +70 °C |
| Body Material | Nickel-plated brass |
| Sensing Face | PBT |
Applications
PLC-based automation systems
Conveyors & bulk material handling
Steel, cement & mining machinery
Heavy-duty industrial control panels
Packaging & assembly lines
Applications requiring fast sensor replacement
What’s in the Box
1 × Autonics PRCML30-15DN Sensor
FAQ
Q1. What does “PRCML” indicate in this model?
PRCML indicates a connector-type inductive proximity sensor designed for long sensing distance.
Q2. Is PRCML30-15DN suitable for PLC inputs?
Yes. It has NPN DC 3-wire output, commonly used with PLC digital inputs.
Q3. What material can this sensor detect?
Only metal objects.
Q4. What is the advantage of non-flush installation?
Non-flush mounting provides a longer sensing distance.
Q5. What is the sensing distance?
15 mm with a standard iron target.
